Camera Spec
Signal System
HDMI: 4KP60, 4KP50, 4KP30, 4KP25, 4KP59.94，
4KP29.97, 1080P60 etc.
3G-SDI: 1080P60, 1080P50, 1080P30, 1080P25,
720P60 etc.
Sensor
1/2.8 inches, CMOS, Effective Pixels: 8.4 Megapixels
Focus Mode
Auto, One Push, Manual
Minimum Illumination
0.5Lux
Shutter
1/30s ~ 1/10000s
White Balance
Auto, Indoor, Outdoor, One Push, Manual, VAR
Backlight Compensation Support
HDR
Support
Digital Noise Reduction 2D/3D Digital Noise Reduction
SNR
≥ 55dB
Anti-flicker
Support
Image Flip
Support
Image Freeze
Support
PoE
Support
Preset Position
255
Network Spec
Video Compression
H.264 / H.265 / MJPEG
Video Stream
First Stream, Second Stream
First Stream Resolution
3840x2160, 1920x1080, 1280x720 etc.
Second Stream
Resolution
1920x1080, 1280x720, 1024x576 etc.
Video Bit Rate
32kbps~102400kbps
Bit Rate Control
VBR, CBR
Frame Rate
50Hz: 1fps~50fps, 60Hz:1fps~60fps
Audio Compression
AAC、G711A
Sampling Rate
48KHz
Audio Bit Rate
48Kbps, 64Kbps, 96Kbps, 128Kbps
Protocols
NDI®|HX2,SRT,TCP/IP, HTTP, RTSP,
RTMP(s), Onvif,DHCP,GB/T 28181, Multicast, etc.
